Supermarket Commercial Building ISO9001 Prefabricated Modular Office Buildings

Qingdao Xinguangzheng Xinyuan Construction Engineering Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap Supermarket Commercial Building ISO9001 Prefabricated Modular Office Buildings from wholesalers

    Buy cheap Supermarket Commercial Building ISO9001 Prefabricated Modular Office Buildings from wholesalers
    • Buy cheap Supermarket Commercial Building ISO9001 Prefabricated Modular Office Buildings from wholesalers
    • Buy cheap Supermarket Commercial Building ISO9001 Prefabricated Modular Office Buildings from wholesalers
    • Buy cheap Supermarket Commercial Building ISO9001 Prefabricated Modular Office Buildings from wholesalers
    • Buy cheap Supermarket Commercial Building ISO9001 Prefabricated Modular Office Buildings from wholesalers

    Supermarket Commercial Building ISO9001 Prefabricated Modular Office Buildings

    Ask Lasest Price
    Brand Name : XGZ
    Model Number : XGZ-SCB011
    Certification : CE,ISO9001
    Price : USD 45-150 per square meter/Negotiable
    Payment Terms : T/T, L/C, Western Union, MoneyGram
    Supply Ability : 15000 tons per month
    Delivery Time : 30-55 days
    • Product Details
    • Company Profile

    Supermarket Commercial Building ISO9001 Prefabricated Modular Office Buildings

    Prefab Steel Structure Commercial Buildings Cheap Supermarket Office Building


    Product Description


    Steel commercial buildings are buildings in which construction steel constitutes a load-bearing structure. Generally, beams, columns, trusses and other components made of section steel and steel plates constitute load-bearing structures. It is a building composed of roof, floor, wall and other enclosure structures.
    Construction section steel usually refers to hot-rolled angle steel, channel steel, I-beam, H-section steel and steel pipe. A building whose components constitute a load-bearing structure is called a profiled steel structure building.
    The steel has high strength and elastic modulus, uniform material, good plasticity and toughness, high precision, convenient installation, high degree of industrialization, and faster construction.


    Product Parameter


    Steel structure commercial building

    Item

    Specification

    Main Structure

    Column

    Q355/Q235 H- steel , Box column is also available

    Beam

    Q355/Q235 H- steel

    Surface processing options

    1. Epoxy zinc-rich primer + epoxy mica intermediate paint (120μm thickness)

    2. Hot dip galvanization


    Sub Structure

    Purlin

    Q355B, C/Z steel section, galvanization 275g/m2

    Angle brace

    Q235B, L- steel

    Cross bracing

    Q235B round bar, L-steel

    Tie bar

    Q235B, round pipe

    Batter brace

    Q235B, round bar

    Roof System

    Roof panel options

    1. Insulated sandwich panel, PU, rock wool, glass fiber, EPS. Two sides is steel sheet. Thickness of roof panel 50mm/75mm/100mm, thickness of steel sheet 0.4mm/0.5mm/0.6mm

    2. Steel plate, thickness 0.4mm/0.5mm/mm

    Gutter options

    1. Galvanized steel gutter, thickness 2.0mm/2.5mm, 3.0mm

    2. Painted, Pre-finished steel gutter, thickness 0.4mm/0.5mm/0.6mm

    Down spout

    PVC pipe

    Steel flashing and cover

    Steel sheet for roof ridge cap, gable wall end cover and corner cover

    OptionsRoof skylight 1.8mm PVC sheet and stainless steel ventilator

    Wall System

    Wall panel options

    1. Insulated sandwich panel, PU, rock wool, glass fiber, EPS. Two sides is steel sheet. Thickness of roof panel 50mm/75mm/100mm, thickness of steel sheet 0.4mm/0.5mm/0.6mm

    2. Steel plate, thickness 0.4mm/0.5mm/mm

    3. Brick wall (provided by client)

    Door

    1. Roller door for truck, size customized

    2. Sliding door for truck, size customized

    3. Access door, steel door, glass door etc

    WindowPVC or Aluminum frame, Fixed, swing, sliding, louver etc, size customized
    Steel flashing and coverSteel sheet end cover and corner cover
    Accessories and fastenersAnchor bolts, chemical bolts, high strength bolts, ordinary bolts, self-drilling screws, rivet etc.

    1. Steel structure commercial building is built over three members connected to each other by bolts and screws: Primary members.

    Steel columns will be H section steel, square tube steel according to different type of buildings.
    Steel beams are usually H section steel.
    2. Secondary members (C or Z purlins, bracing...)
    3. Roof and wall sheeting or sandwich panel (EPS, fiberglass wool, PU sandwich panel) Other building components (Rolling doors, aluminium windows, etc.)
    4. The entire primary members and secondary members are designed and fully fabricated including cut-to-length, punching, drilling, welding and performing in the factory before shipping to the site for erection. At the site, all components are assembled and jointed via nut & bolt connections; thereby reducing the costs and assembly times.
    5. These buildings can be provided with different structural and non-structural additions such as ventilators, doors & windows, trusses, mezzanine floors, canopies, crane, insulation…, based on the customer's requirements.

    Supermarket Commercial Building ISO9001 Prefabricated Modular Office Buildings


    Application


    Steel structure commercial buildings find applications in various industries and sectors. Here are some key areas where steel structure commercial buildings are commonly used:

    1. Office Building

    Steel structures provide flexible and efficient spaces for office complexes, accommodating multiple floors and open layouts.

    2. Warehouse and Distribution Center

    Steel buildings provide large spaces for storage, logistics, and distribution operations.

    3. Manufacturing Factory

    Steel structures are ideal for manufacturing plants, providing ample floor space for production lines and equipment.

    4. Exhibition Hall and Convention Center

    Steel buildings offer vast spaces for hosting exhibitions, trade shows, conferences, and other large-scale events.

    Supermarket Commercial Building ISO9001 Prefabricated Modular Office BuildingsSupermarket Commercial Building ISO9001 Prefabricated Modular Office BuildingsSupermarket Commercial Building ISO9001 Prefabricated Modular Office Buildings


    Product Advantages


    Compared with ordinary buildings, steel structure commercial buildings have the following advantages:

    1. Size can be customized
    2. Large span, clear span can reach to 70m without middle colums
    3. Environment protective, no garbage caused, low demand of foundation
    4. Doors, windows, and interior partitions can be customized and flexibly fixed
    5. Beautiful appearance, different colors for the wall and roof cladding
    6. Cost saving and convenient transportation
    7. Fast installation and easy to maintenance
    8. Anti-rust and normally more than 50years using lifespan, surface treament can be paint or hot dip galvanization
    9. Safe and stable, can resist 8 grade earthquake
    10. Structure can be designed according to the required live load and local snow load and wind load, can resist typhoon/hurricane


    Design&Quote


    If you already have the project drawings, please send to us, we will directly quote for you, if you only plan or idea, please also contact us, we will provide you with professional design, and quote.

    Could you pls advise your requirement for the steel structure commercial building project?
    1. Project location;
    2. Dimension (length*width*eave height);
    3. There is mezzanine or not? How many kgs will be loaded per square meter on mezzanine if have?
    4. Steel sheet or sandwich panel roof and wall;
    5. Snow load if applicable;
    6. Wind speed;
    7. There is crane inside the building or not?;
    8. Any other particular requirements?

    Supermarket Commercial Building ISO9001 Prefabricated Modular Office Buildings


    Project Process


    The cooperation process for steel structure projects typically follows the following steps:

    1. Inquiry

    The process begins when a customer sends an inquiry expressing their interest in a steel structure project.
    2. Design and Quotation

    The design and quotation phase involves close collaboration between our team and the customer. Our team creates a customized solution based on the customer's requirements and provides a detailed quotation for the project.
    3. Project Approval

    Once the customer approves the design and quotation, the project moves forward to the manufacturing phase.
    4. Manufacturing and Fabrication

    The steel structure components are manufactured and fabricated in our factory. Skilled workers and advanced machinery are utilized to ensure high quality and precision.
    5. Shipping and Logistics

    After completion, the finished steel components are carefully packaged and shipped to the customer's country. Proper logistics arrangements are made to ensure safe and timely delivery.
    6. Installation Support

    We provide customers with construction drawings, installation videos, and online guidance to assist with the installation process. If requested, we can also send experienced construction personnel to the customer's country to provide offline installation guidance and support.

    Throughout the cooperation process, we prioritize close communication and collaboration with the customer to ensure your satisfaction and the successful completion of the steel structure project.

    Supermarket Commercial Building ISO9001 Prefabricated Modular Office Buildings


    Contact us


    Any request for steel commercial building, please no hesitate to contact Della by followings:
    Contact: Della
    Email: della@qdxgz.cn
    Mobile/Whatsapp/Wechat: +8615898860020


    FAQ


    1. Are you trading company or manufacturer ?
    We have our own steel structure, steel sheet and sandwich panel manufacturing factories. Welcome to our company to see our products and discuss your project.
    2. Can you offer design service?
    Yes,we have an engineer team and can design for you according to your requirements.Architectural drawing,structure diagram,processing detail drawing and installation drawing will be made and let you confirm in different time of the project.
    3. What is the delivery time?
    It depends on the quantities of order. Generally, the delivery time will be within 30 to 55 days.
    4. How to install after the goods arriving destination?
    We will provide detailed illustrations to you. If it is necessary, we will send technicians to help you. However, the visa fee,air tickets, accommodation, wages will be paid by buyers.
    5. What about packaging and shipping?
    The package of steel structure material is steel pallet. After loading into the containers, they will be sent to the Qingdao Port and transported by Sea.
