Durable Multi-Story Steel Structure Commercial Buildings For Businesses

Product Description

Steel commercial building is composed by square tube columns, steel roof and platform beam, steel decking board, roof cladding, wall cladding and accessories like studs, bolts, etc. Aluminium windows, door, glass curtain wall, plaster board ceiling and floor tiles can be also provided if need.
As a rising prefabricated buildings, steel structures differs from precast concrete in that its main load-bearing components are all made of steel, consisting of steel beams, columns, trusses and other components made of section steel and steel plates. Each component is usually connected by weld seams, bolts or rivets on site.

The main components of steel structure commercial building are:

1. Main frame
The main frame members include columns, beams and other supporting members. The shape and size of these members vary based on the application and requirements. The frame is erected by bolting the end plates of connecting sections together.

All the steel sections and welded plate members are designed in accordance with the applicable sections as per the latest international codes and standards such as GB and IS to meet all the customer specifications.
2. Roof and wall cladding
Roof for steel structure commercial building can be sandwich panel, stone painted sheet or pouring concrete depending on roof slope and customers’ requirement.
Wall is usually PU sandwich panel or rock wool sandwich panel to make nice looking and good heat insulation.
3. Steel decking board
Decking board is for the floor of multi-storey metal office building, its effective width is 688mm or 750mm. Decking board is on steel platform as form board and support of concrete.

Steel structure commercial buildings find applications in various industries and sectors. Here are some key areas where steel structure commercial buildings are commonly used:

1. Office Building

2. Supermarket

3. Exhibition hall

4. Showroom

Product Advantages

Advantages of pre-engineered commercial building:
1. Lower price and shorter construction period.
2. Easy to assemble and disassemble.
3. High durability and liable to maintain.
4. Light weight of steel structure members & convenient to ship and transport.
5. Good fireproofing performance with rock wool sandwich panel as roof and wall.
6. Good performance of heat-insulation with sandwich panel as roof and wall.
7. Beautiful appearance with various sheeting colors and shapes.
8. Various designs available, customized designs acceptable.
9. Healthy and safety, less waste during pre engineered commercial building constructs.

Design and Quote

If you already have the project drawings, please send to us, we will directly quote for you, if you only plan or idea, please also contact us, we will provide you with professional design, and quote.

Could you pls advise your requirement for the steel structure commercial building project?
1. Project Progress: Is Land Purchased? Is it licensed by the government?
2. Location: In which country will it be built?
3. Local Climate: Wind speed, Snow load (max. Wind speed)
4. Dimension: Length*width*height
5. Roof and Wall: Determine the panel material, such as color steel panel, and metal sandwich panel.
6. Windows and Doors: What material, quantity, and type?

Installation process of steel structure commercial building

1. Anchor bolt will be pre embedded according to design drawing: Anchor bolt plan.

When install, it need use template to fix, positional deviation is ±5mm. Screw thread should be protected.
2. Steel column installs according to installation drawing- column plan.

Column foot plate should be welded cycle by continuous welding fillet on site.
3. Floor platform will be according to installation drawing -first floor steel beam plan, second floor steel beam plan.

Column and beam connected part, the plate will be welded in site; Welding joint bottom will be welded with plate.
4. Roof beam will be according to installation drawing- Roof beam plan.

Oblique beams should be welded cycle by continuous welding fillet on site.
5. Roof purlin, steel stair and decking floor will be installed according to installation drawing.

Diamond plate, decking floor and stair joint of stair transfer platform can be cut according to the site installation.
6. Pay attention to length when install the gutter.

Water funnel will be parallel with wall.

Why choose us to offer steel structure commercial building:
1. We have a group of professional engineers, most of whom has more than 10 years experiences in architecture field. our company has got a various of experiences in design, manufacture, installation and so on. The work staff have excellent skills. Some of them had helped customers to install the warehouse around the world.
2. We will offer one stop service. construction drawing,calculation sheet will be offered to help you get construction permit. Foundation design could be free made if you need. We could make 3D drawings to show the view. What's more, Installation drawings will be offered and Steel structure column,beams will be marked number on it to help you install.
3. We will send you extra bolts,purlins,panels incase any damage when install.
4. Efficiency is our pursuit. Every inquiry ,emails will be replied immediately. Every questions will be paid high attention.
5. We also have possessed more than 40 sets of large precise and domestically advanced processing equipments, including large gantry planing machines, automatic submerged arc welding machines, assembling machines, slitters, shot blasting machines and soon.
6. We will offer details packing list for every container when load so it will be easier to unload.
7. "Moral personality decides product quality." is our guarantee to the products. "Customers come first." is our everlasting pursuit. Believe your choose, we'll give you a satisfied answer.

1. You are manufacture factory or trading company?
We are manufacture factory. And you are welcomed to visit us for inspection. The quality control flow will show you ourprofessional. Also you will enjoy the best quality and competitive price.
2. Can you offer designing service?
Yes, we have more than 50 design engineers. We could design full solution drawings as per your requirments. They use software: Auto CAD,PKPM, MTS, 3D3S, Tarch, Tekla Structures(Xsteel)V12.0.etc.
3. Do you offer guiding installation on site overseas?
Yes, usually we will send you the detailed installation drawing, if you need, we can provide the service of installation, supervision and training by extra. We can send our professional technical engineer to supervise installation on site overseas.
4. How can I get a quotation for my project?
Pls no hesitate to send me message here or Email me. I will reply to you as soon as possible.
6. What about packaging and shipping?
The package of steel structure material is steel pallet. After loading into the containers, they will be sent to the Qingdao Port and transported by Sea.
